Air Velocity Transducer TSI Model 8465

Features

Range: 25 to 10,000 fpm (0.127 to 50.8 m/s), selectable
Accuracy: +2.0% of reading¹,
¹From 64.4 to 82.4°F (18 to 28°C), outside this range and within temperature
compensation range add 0.11% per °F (0.2% per °C)
+0.5% of full scale of selected range

Field selectable range:
25 ft/min to 200, 250, 300, 400, 500, 750, 1,000, 1,250, 1,500, 2,000, 2,500, 3,000, 4,000, 5,000, 7,500,
10,000 ft/min (0.125 m/s to 1.0, 1.25, 1.50, 2.0, 2.5, 3.0, 4.0, 5.0, 7.5, 10.0, 12.5, 15.0, 20.0, 25.0, 30.0, 40.0, 50.0 m/s)

Repeatability: <+1,0% of reading³,
³Standard deviation based on one minute average from 100 to 1,000 fpm (0.5 to 5.0 m/s)

Response to flow: 0.2 sec⁴,
⁴For 63% of final value, tested at 1,500 fpm (7.5 m/s)

Temperature range:
Compensation: 32 to 140°F (0 to 60°C)
Operating (electronics): 32 to 200°F (0 to 93°C)
Operating (sensor): 32 to 200°F (0 to 93°C)
Storage: 32 to 200°F (0 to 93°C)

Resolution (minimum): 0.07% of selected full scale

Input power: 11 to 30 VDC or 18 to 38 VAC, 350 mA max^6
6Input voltage must be maintained within specifications at the transducer

Output:
Impedance: Voltage mode: less than 1 ohm, 20mA
max source current
Resistance: Current mode: 500 ohms maximum load
Signal: Field selectable 0 to 5V, 0 to 10V,
0 to 20, 2 to 10V, mA, 4 to 20 mA
Time constant: Field selectable 0.05 to 10 seconds

Probe length: 3 in., 6 in., 9 in., 12 in. (7.5 cm, 15 cm, 22.5 cm, or 30 cm)

All models contain on-board electronics and calibration curves that provide a linear signal output. This linear signal is sent out as either a current (mA) or a voltage (V) signal, allowing output to a variety of data loggers or data acquisition systems. In addition, the current and voltage output ranges are user-selectable for your convenience.

Associated services

. First level maintenance and repair work performed by Aerometrik.

. Taking charge of and monitoring the metrology of this equipment with TSI.
